Enclosure Characteristics |
Die-cast aluminum with white powder coating |
|
Processor |
Atheros MIPS 74Kc, 720 MHz |
|
Memory |
RAM: 128 MB DDR2 SDRAM
Flash: 16 MB NOR |
|
Networking Interface |
1 x 10/100/1000 Mbps Ethernet port |
|
RF Connections |
2 x RP-SMA (Waterproof )
1 x GPS (Waterproof ) |
|
LEDs |
Power
LAN
GPS
4 x Signal Strength |
|
Max Power Consumption |
8.5 W |
|
Power Supply |
24 V, 0.5 A Gigabit PoE adapter |
|
Power Method |
Passive PoE (Pairs 4, 5+; 7, 8 Return) |
|
Voltage |
18-26 VDC |
|
ESD/EMP Protection |
± 24 KV Air / Contact |
|
Temperature & Humidity |
Operating Temperature: -40 to 176°F / -40 to 80°C
Operating Humidity: 5 to 95% non-condensing |
|
Shock and Vibration |
ETSI300-019-1.4 |
|
Modes |
Access Point, station |
|
Services |
Web Server, SNMP, SSH Server, Telnet , Ping Watchdog, DHCP, NAT, Bridging, Routing |
|
Utilities |
Antenna Alignment Tool, Discovery Utility, Site Survey, Ping, Traceroute, Speed Test |
|
Distance Adjustment |
Dynamic Ack and Ackless Mode |
|
Power Adjustment Range |
Software Adjustable UI or CLI |
|
Security |
WPA2 AES only |
|
QoS (Quality of Service) |
Supports Packet Level Classification WMM and User Customer Level: High/Medium/Low |
|
Statistical Reporting |
Up Time, Packet Errors, Data Rates, Wireless Distance, Ethernet Link Rate |
|
Channel Sizes |
PtP Mode: 10/20/30/40/50/60/80 MHz
PtMP Mode: 10/20/30/40 MHz |
|
Other Specifications |
Remote Reset Support, Software Enabled/Disabled, VLAN Support, 256QAM, GPS, TX Filter |
|
Wireless Approvals |
FCC, IC, CE |
|
RoHS Compliance |
Yes |
|
Operating Frequency |
Worldwide: 5150 - 5875 MHz DTS: 5725 - 5850 MHz |
|
Output Power |
Output Power 27 dBm
Tx Power Specifications
Modulation: airMAXac
Data Rate / Avg. Tx / Tolerance
1x BPSK (½) 27 dBm ± 2 dB
2x QPSK (½) 27 dBm ± 2 dB
2x QPSK (¾) 27 dBm ± 2 dB
4x 16QAM (½) 27 dBm ± 2 dB
4x 16QAM (¾) 27 dBm ± 2 dB
6x 64QAM (2/3) 27 dBm ± 2 dB
6x 64QAM (¾) 26 dBm ± 2 dB
6x 64QAM (5/6) 25 dBm ± 2 dB
8x 256QAM (¾) 23 dBm ± 2 dB
8x 256QAM (5/6) 22 dBm ± 2 dB
RX Power Specifications
Modulation: airMAXac
Data Rate / Sensitivity / Tolerance
1x BPSK (½) -96 dBm ± 2 dB
2x QPSK (½) -95 dBm ± 2 dB
2x QPSK (¾) -92 dBm ± 2 dB
4x 16QAM (½) -90 dBm ± 2 dB
4x 16QAM (¾) -86 dBm ± 2 dB
6x 64QAM (2/3) -83 dBm ± 2 dB
6x 64QAM (¾) -77 dBm ± 2 dB
6x 64QAM (5/6) -74 dBm ± 2 dB
8x 256QAM (¾) -69 dBm ± 2 dB
8x 256QAM (5/6) -65 dBm ± 2 dB |
|
Dimensions |
3.47 x 1.58 x 9.06" / 88 x 40 x 230 mm |
|
Weight |
14.11 oz / 400 g |
