Technical

Processor

MIPS 24 K, 400 MHz

USB Port

USB 2.0 type A (reserved for future use)

System Memory

64 MB

Code Storage

8 MB

PoE Method

Passive

Networking Interfaces

Management Port

1 x 10/100 Ethernet port

Data Ports

5 x 10/100/1000 Ethernet ports

PoE Configurable Per Port

Data Ports

Off/24 V

LEDs Per Port

Management Port

Power/link/activity

Data Ports

PoE, speed/link/activity

Electrical

Power Input

24 VDC, 2.5 A power adapter (included)

Power Consumption

Maximum: 60 W

PoE Out-Voltage Range

22 to 24 VDC

Maximum PoE Wattage Per Data Port

11.5 W

ESD Rating

Air: 24 kV
Contact: 24 kV

Environmental

Operating Temperature

-13 to +131°F (-25 to +55°C)

Operating Humidity

90% (non-condensing)

Certification and Compliance

Certifications

CE, FCC, IC

General

Button

Reset

Wall-Mount

Yes

Dimensions

7.7 x 3.4 x 1.0" (197.0 x 87.5 x 27.3 mm)

Weight

8.8 oz (250.0 g)
