Online management features
|
-
Online array expansion
-
Online array expansion
-
Online logical drive extension
-
Online RAID level migration
-
Online stripe size migration
-
Online mirror split, recombine and rollback
-
Online and high performance offline Rapid Parity Initialization (RPI)
-
Unlimited global online spare assignment
-
User selectable expand and rebuild priority
-
User selectable expand and rebuild priority
-
User selectable expand and rebuild priority
-
Supports predictive spare activation
|
|
Ports
|
Distributed across 1 internal x8 Mini-SAS double-wide connector
|
|
Key features
|
-
Storage interface (SAS/SATA)
-
8 physical links across 1 x8 internal port
-
12 Gb/s SAS, 6 Gb/s SATA technology
-
Mix-and-match SAS and SATA drives to the same controller
-
Support for SAS tape drives, SAS tape autoloaders and SAS tape libraries
-
4GB FBWC
-
PCI express Gen3 x8 link
-
RAID 0, 1, 10, 5, 50, 6, 60, 10 Advanced Data Mirroring (ADM)
-
RAID or HBA mode
-
Legacy and UEFI boot operation
-
Up to 200 physical drives
-
Up to 64 logical drives
-
HPE SmartCache (Optional license)
-
HPE Secure encryption (Optional license)
-
FIPS 140-2 validation complete (Certificate #2506)
-
HPE SSD smart path
-
VMware virtual SAN certified
-
RPI
-
Rapid rebuild
-
Drive erase
-
Performance optimization-degraded reads and read coalescing
-
Power efficiency
-
Seamless upgrades to and from other HPE Smart Array controllers
-
Recovery ROM to protect against controller ROM corruption
-
Low-profile standard PCI express plug-in card
|
|
Performance
|
-
12 Gb/s SAS (1200 Mb/s theoretical bandwidth per physical lane)
-
6 Gb/s SATA (600 Mb/s theoretical bandwidth per physical lane)
-
PCI express Gen3 x8 link width
-
4GB 72-bit wide DDR3-1866 FBWC provides up to 14.9 Gb/s maximum cache bandwidth
-
Read ahead caching
-
Write-back caching
|
|
Fault prevention
|
The following features offer detection of possible failures before they occur, allowing preventive action to be taken:
-
Self Monitoring Analysis and Reporting Technology ( SMART) was first developed by HPE which detects possible hard disk failure before it occurs, allowing replacement of the component before failure occurs
-
Drive parameter tracking monitors drive operational parameters, predicting failure and notifying the administrator
-
Dynamic sector repairing continually performs background surface scans on the hard disk drives during inactive periods and automatically re-maps bad sectors, ensuring data integrity
-
Smart array cache tracking monitors integrity of controller cache, allowing pre-failure preventative maintenance
|
|
Fault recovery
|
Minimizes downtime, reconstructs data, and facilitates a quick recovery from drive failure
-
Recovery ROM: This feature protects the user from a firmware image corruption by storing a redundant copy of the firmware image. If the active firmware image becomes corrupt, the controller will use the redundant firmware image and continue operating
-
On-line spares: There is no limit to the number of spare drives that can be installed prior to drive failure. If a failure occurs, recovery begins with an on-line spare and data is reconstructed automatically
-
DRAM ECC detects and corrects data bit errors
|
|
HPE SmartCache
|
-
The HPE SmartCache feature is a controller-based read and write caching solution in a DAS environment that caches the most frequently accessed data (hot data) onto lower latency SSDs to dynamically accelerate application workloads
-
The HPE SmartCache architecture is flexible and supports any HPE ProLiant Gen9 supported HDD for bulk storage and any HPE ProLiant Gen9 supported SSD as an accelerator
-
HPE SmartCache is deployed and managed using the HPE SmartStorage Administrator (HPE SSA)
-
HPE SmartCache is an optional license (See related options for more information on the license)
|
|
HPE SSD smart path
|
The following operating systems are supported by the HPE SSD smart path feature:
-
Microsoft Windows Server 2008
-
Microsoft Windows Server 2008 R2
-
Microsoft Windows Server 2012 R2
-
Red Hat Enterprise Linux 6.1, 6.2, 6.3, 6.4, and 6.5
-
SUSE Linux Enterprise Server 11 (SP1, SP2, SP3)
-
VMware ESXi 5.0 U3
-
VMware vSphere 5.1 U2 and vSphere 5.5
|
